Inline direct driven cabinet fan

BOX-D

General Description

Direct driven centrifugal cabinet fans with special acoustic lining for improved sound radiation control, from 175 to 6,000 CMH airflow range.

The low noise level is due to their plenum lined with acoustic material, that allows a remarkable reduction of noise level, inevitably generated by the fan. The blower consists of a double inlet forward curved centrifugal fan with built-in motor.

Their main characteristic is the low noise level which makes them ideal for urban environments (apartments, houses, bar, restaurants, gymnasiums, offices) and industrial sites where the noise is a problem.

The low noise level is due to their plenum lined with acoustic material, that allows a remarkable reduction of noise level, inevitably generated by the fan.

The blower consists of a double inlet double width forward curved centrifugal fan with built-in motor.

Application

HVAC unit’s industrial hoods (without material handling, chemical fumes).
Painting rooms (with effective filtration system).
HVAC unit’s industrial cooling.
HVAC OEM production premises.
Recirculation and air conditioning system.
Multifamily – structures apartment, condos, hotels, dryers, residential, gymnasiums kitchen and bathrooms.

Construction

Profile less cabinet is manufactured in PPGI sheet with removable access panel to allow easy access to fan and motor.
The blower is fitted using suitable support feet and is completely isolated from the casing by anti-vibration mounts and gaskets.
Acoustic lining in self-extinguishing technopolymer.
Double inlet blower, forward curved, with direct drive built-in asynchronous motor, single-phase or three-phase, particularly suitable for speed regulation (using the suitable speed regulators shown in this catalogue).
Flanged inlet and outlet for easy duct work.

Upon Request

Different discharge orientation.
Electronic and self-transformer speed regulators.
Pre-filtered section (G2/G4).
Customized cabinet sizes.
Construction with the Aluminium extruded profile.
Versions with double skin panels (20 mm thick) only in Al extruded profile.
Revit models for BIM.
